Oregon Shelf

This map shows the Regional Cabled Array infrastructure as installed in 2019. Credit: M. Elend, University of Washington.

The Oregon Shelf site (80 m depth) is the shallowest OOI site to have cabled assets. It includes both uncabled and RCA infrastructure, and utilizes fixed and mobile assets to observe cross-shelf and along-shelf variability in the coastal upwelling region of the Oregon and Washington coasts. This site is designed to examine biogeochemical and physical oceanographic processes within such highly productive coastal environments, specifically, the impacts of wind-driven upwelling of nutrient-rich currents on biological communities and hypoxia events. At the shelf site, roughly 20-30 km from shore, upwelling fronts, alongshore jets, and plankton blooms can be found.

The seafloor in this domain is muddy, and near-bottom hypoxia has been observed to peak in this area.with the uncabled Endurance Array sites, the Oregon Shelf site contains fixed sensors at the top and bottom of the water column paired with an adjacent water column profiler. Mooring lines provide synoptic, multi-scale observations of the eastern boundary current regime. Coastal Gliders bridge the distances between the fixed sites and allow for line transects and adaptive sampling.

The low power junction box (LJ01D), which provides power, bandwidth, and communications to RCA instrumentation at the Oregon Shelf site, is now home to a vibrant community of sea anemones. Credit: UW/NSF-OOI/WHOI. V19.

The coastal ocean off Oregon is characterized by a relatively narrow shelf, upwelling and downwelling driven by wind, and fresh, buoyant water emerging from regional rivers (Trowbridge, et al., 2019). The most important of these is the Columbia River, the largest source of freshwater to the US west coast, and a major focus of the Endurance Array. Regional mesoscale variability is forced by bathymetry, fluid dynamical instabilities, and coastally trapped waves. At the largest scales, year to year variability is caused by fluctuations in the tropical Pacific (e.g., El Niño Southern Oscillation), as well as variations in the large-scale circulation of the North Pacific (e.g., Pacific Decadal Oscillation).

The regional ecosystem is a part of the larger California Current Ecosystem (Mackas, 2006), and is both chemically and biologically variable. Oregon and Washington coastal waters are home to a diverse range of fisheries that rely on the transport of nutrients into the euphotic zone via upwelling deep water. This injection of nutrients leads to blooms of phytoplankton, which form the base of the oceanic food web. The arrival time and scale of the spring-summer upwelling season is crucial to the regional ecosystem. Interannual variability can also cause swings in population dynamics, for example between northern, “fatty” zooplankton and southern, “skinny” zooplankton (Peterson and Schwing, 2003).

The ROPOS ROV releasing a tungsten carbide calibration sphere on the Oregon Shelf bioacoustic sonar platform. The orange circles are the sonar transducer heads. Credit: NSF-OOI/UW/CSSF; Dive R1792; V14
Creative Commons License

In recent years, hypoxic and even anoxic events have regularly occurred off Washington and Oregon as they have in upwelling regions worldwide (Grantham et al., 2004; Chan et al., 2008). During these same years, the threat of Ocean Acidification to marine organisms in this area and across the California Current Ecosystem has become very clear (Feely et al., 2008; Barton et al., 2012; Klinger et al., 2017).
